Description
Rigol DS1054Z Digital Oscilloscope
The 1000Z Series is RIGOL’s Digital Oscilloscope platform for Basic Visualization. It offers unprecedented value in customer applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. This 1000Z Series 4 channel oscilloscopes is the 50MHz version with a 7 inch display and RIGOL’s UltraVision technology.
Oscilloscopes/Digital Oscilloscopes Template | |
|---|---|
| Bandwidth | 50 MHz |
| Channels | 4 |
| Sampling Rate | 1 GS/S Sampling Rate 1 GSa/s (Single Channel), 500 MSa/s (Dual Channels), 250 MSa/s ((Full Channel) |
| Memory | 12 MP [megapoints] (12288 kB) |
| Rise Time | 7 ns |
| Screen Size | 7 IN |
| Bits | 8 |
Product General Attributes | |
| Unique Features | The Number 1 Selling Oscilloscope of 2015 4 Channels, 50 MHz Bandwidth UltraVision: Deeper memory 12 Mpts upgradable to 24 Mpts via a software key ( this is not a typo. This scope has 12 Megs of Memory standard! ) Up to 30,000 wfms/s Waveform capture rate HUGE 7” screen WVGA(800X480) TFT USB HOST, USB DEVICE, LAN, Aux (TrigOut /PassFail) Incredible display with multi-Level intensity grading display Realtime waveform Record,Replay, function (Opt.) A variety of Math Functions FFT function standard A variety of Trigger Functions Optional Serial Bus Triggering and Decoding functions(RS232,I2C,SPI) These are software keys Standard Mask test function Automatic Measurements with Statistics This scope is truly amazing for the price. Deep memory, beautiful screen, 4 channels, free software, USB host interface, standard usb interface on the back, LAN/Ethernet standard, Aux (TrigOut /PassFail) |
| Warranty | 3 YEARS |
| Safety Approval | CE, CSA |
| Interfaces I/O | LAN / Ethernet, LXI, USB Host, USB |
| Product Weight | 3 KILOS (6.61 LBS) |
| Product Height | 12.00 IN |
| Product Length | 18.00 IN |
| Product Width | 11.00 IN |
| Shipping Weight | 4.2 KILOS (9.26 LBS) |
| Data Logging | Yes Data Logging USB Host Can save to USB host or internal memory, plus |
| HTS/Schedule B Number | 9030201000 |
| ECCN Number | 3A992.g |
| Calibration Included | Factory Calibration |
| Power Supply Voltage | 120V 50/60 Hz |
| Country of Origin | China |
| Shipping Height | 12.00 IN |
| Shipping Length | 18.00 IN |
| Shipping Width | 11.00 IN |
