Simpson 00160 DC Current Round Style Panel Meter
27 people are viewing this product right now
Original price was: $151.18.$128.49Current price is: $128.49.
Shipping calculated at checkout.
Estimated delivery:5 days
25A—- 0-300 DCA 3.5 UL RND
- ±2% Full Scale Accuracy
- UL Recognized
- Phenolic Case with Glass Windows
- Calibration Not Affected By Steel Mounting
- Distinctive Case Style
- Two Popular Sizes: 2-1/2″ & 3-1/2″
Guarantee Safe and Secure Payment Checkout
Description
For industrial or commercial applications, the Round style panel meter offers maximum reliability and ±2% full scale (F.S.) accuracy. With a black phenolic case and glass window for optimum viewing, the Round style meter is a popular replacement. All DC units have pivot and jewel suspensions that are spring-loaded for shock protection. The selfshielded meter movement prevents magnetic interaction between the meter and a steel panel. Two popular sizes of 2-1/2″ and 3-1/2″ are available to measure various voltage ranges up to 1000 amps. DC current meters are self contained for ranges up to and including 50 amperes. Higher range DC current meters require external shunts.
Panel Meters/Panel Meters Template | |
|---|---|
| Type (Panel Meter ) | Analog |
| Style (Panel Meter) | Circular |
| Number of Inputs (Panel Meters) | Single |
| Mounting (Panel Meter) | Panel Mount |
| Input (Panel Meters) | Current |
| Size-Circular | 2.82 IN Size-Circular Circular Panel Cut Out Size, Unit_id and unit_name Missing |
| Size-Face Width | 3 1/2 in |
| Process Output | No |
| Control / Alarm Setpoints | No |
| Water Proof | No |
| Splash Proof | No |
| Relay Output | No |
Product General Attributes | |
| Country of Origin | United States |
| Other Information | Ranges: 250mV, 1V, 2.5V, 10V, 50V, 250V, 500V, 1000V Accuracy: 2% of full scale Sensitivity: 20K per volt Ranges: 2.5V, 10V, 50V, 250V, 500V, 1000V Accuracy: 3% of full scale Sensitivity: 5K /volt 5 Ranges: -20 to +50dB Reference: 0dB= 1mW into 600O Ranges: 50µA, 1mA, 10mA, 100mA, 250mA, 500mA Accuracy: 2% of full scale Voltage Drop: (Nominal): 250 mV or 50 mV on 50µA, (2ranges) 50 mV, all others Ranges: Rx1, Rx10, Rx100, Rx1K, Rx10K Accuracy: 3° of arc Maximum Indication: 0-3K, 0-30K, 0-300K, 0-3M, 0-30M |
